DOI : 10.11973 / lh jy -wl202106007


                  T91      钢高温过热屏自动焊裂纹分析及工艺确定




                                                     赵志明 ,夏   静    2
                                                           1

                                ( 1. 太原锅炉集团有限公司,太原 030008 ; 2. 山西医科大学,太原 030001 )
                    摘   要: 选用不同硫、 磷含量的焊丝, 采用扁钢不开坡口和开 K 型坡口焊接工艺对 T91 钢高温
                 过热屏进行自动焊接, 并对焊接接头质量进行了分析。结果表明: T91 钢高温过热屏的最佳自动焊
                 接工艺为, 选用低硫、 磷含量的焊丝, 采用扁钢开 K 型坡口的焊接工艺。选用低硫、 磷含量的焊丝,
                 相比高硫、 磷含量的焊丝来说, T91 钢高温过热屏的结晶液化裂纹敏感性显著降低了。采用扁钢开
                K 型坡口焊接工艺, 相比扁钢不开坡口焊接工艺来说, 焊缝根部不易萌生微裂纹。

                    关键词: T91 钢;高温过热屏;自动焊;焊丝;焊接工艺




                    中图分类号: TG115.6    文献标志码: A    文章编号: 1001-4012 ( 2021 ) 06-0034-04

                   CrackAnal y sisandProcessDeterminationofAutomaticWeldin g for

                                 T91SteelHi g hTem p eratureSu p erheatScreen

                                                             1
                                                              ,
                                                  ZHAOZhimin g XIAJin g 2

                ( 1.Tai y uanBoilerGrou pCo. , Ltd. , Tai y uan030008 , China ; 2.ShanxiMedicalUniversit y , Tai y uan030001 , China )


                     Abstract : Theweldin gwireswithdifferentsulfurandp hos p horuscontentwereselected , andtheflatsteel

                without g rooveandK- g rooveweldin gp rocesseswereusedtoautomaticweldT91steelhi g htem p eraturesu p erheat

                scree , andtheweldin gj oint q ualit ywasanal y zed.Theresultsshowthatthebestautomaticweldin gp rocessofthe

                T91steelhi g htem p eraturesu p erheatscreenwastoselecttheweldin gwirewithlowsulfurandp hos p horuscontent

                andado p ttheweldin gp rocessofflatsteelwithK- g roove.Com p aredwiththewirewithhi g hsulfurandp hos p horus

                content , thesensitivit yofcr y stallizationli q uefactioncrackoftheT91steelsu p erheatselectedthewirewithlow

                sulfurandp hos p horuscontentwassi g nificantl yreduced.Com p ared withtheflatsteelwithoutg roove weldin g

                p rocess , theflatsteelwithK- g rooveweldin gp rocesswasado p ted , therootofweldseam wasnoteas y tocrack.


                     Ke y words : T91 steel ; hi g htem p eraturesu p erheatscreen ; automatic weldin g ; weldin g wire ; weldin g
                p rocess
              T91 钢是以 T9 钢为基础的, 通过降低碳含量、
                                                              1  试验材料与试验方法
            增加合金元素钒和铌、 控制氢和铝含量得到的钢种。
            T91 钢不仅具有高的抗氧化性和耐高温蒸汽 腐蚀                          1.1  试验材料
            性, 而且具有良好的冲击韧性和高稳定的持久塑性                                选用硫、 磷元素含量较高的国内某厂商生产的
            和热强度。主要用于制造高温过热器和壁温 小于                             焊丝和硫、 磷元素含量较低的国外某厂商生产的焊
            625 ℃ 的亚临界、 超临界锅炉高温再热器钢管。由                         丝, 分别进行扁钢不开坡口和开 K 型坡口的 T91 钢

            于 T91 钢高温过热屏的结构原因, 其拘束应力大,                         水冷壁自动焊接试验。对所有用于 T91 钢管排的

            焊后易出现连续或断续裂纹。为防止类似缺陷的产                             原材料( 母材、 焊材) 按JB / T3375-2002 《 锅炉用材
            生, 作者进行了一系列针对性试验, 通过接头质量分                          料入厂验收规则》 进行理化检验。化学分析试样
                                                                               [ 1 ]

            析, 确定了 T91 钢高温过热屏的焊接工艺。                            按 ASTM E1806-18 《 钢和铁化学成分测定的取样

                                                                            [ 2 ]
                                                               标准实施规程》 对表面进行研磨预处理后, 再用赛
                收稿日期: 2020-09-27
                                                               默飞 ARL3460 型分析仪按 ASTM E415-17 《 用火
                作者简介: 赵志明( 1987- ), 男, 高级工程师, 主要从事电站锅炉
                                                               花原子发射光谱法分析碳和低合金钢的标准试验方
            压力容器金属材料的失效分析工作, zhaozhimin g ak@126.com
