DOI : 10.11973 / lh jy -wl202101006

                         电站锅炉珠光体铁素体耐热钢薄壁管的


                                            现场金相检验方法




                                                         陈思思

                                             ( 咸阳市特种设备检验所,咸阳 712000 )
                    摘   要: 对于一般的电站锅炉主蒸汽管道, 管壁厚且直径大, 现场金相检验易于操作。但是对于

                 薄壁管, 尤其是高温、 高压受热面, 壁厚一般为 3.0~4.0mm , 外径一般为 30~50mm , 现场金相检
                 验制样的难度极大。如果割管取样, 不仅恢复难度大, 也影响设备的使用性能。因此在现场金相检
                 验的基础上, 研究了一种针对电站锅炉高温受热面( 珠光体铁素体耐热钢薄壁) 管的金相检验方法。
                 结果表明: 使用便携式金相显微镜, 利用该方法得到的显微组织形貌较清晰, 分析结果准确、 可靠。
                 该方法不仅优化了检验环节, 而且缩短了检验时间、 提高了企业的经济效益, 同时也避免了割管的
                 损伤, 解决了薄壁管焊接恢复难的问题。




                    关键词: 电站锅炉;受热面;薄壁管;现场金相检验;便携式金相显微镜

                    中图分类号: TG142.1    文献标志码: A    文章编号: 1001-4012 ( 2021 ) 01-0025-04

              FieldMetallo g ra p hicExaminationMethodofPearliticFerriteHeatResistant

                                    SteelThin-walledPi p eforUtilit yBoiler

                                                        CHENSisi

                               ( Xian y an gS p ecialE q ui p mentIns p ectionInstitute , Xian y an g712000 , China )


                     Abstract : Forthe g eneralmainsteamp i p elineofutilit yboiler , the p i p ewallisthickandthediameterislar g e , so

                thefield metallo g ra p hicexaminationiseas ytoo p erate.However , forthethin-walledp i p e , es p eciall yforthehi g h-

                tem p eratureandhi g h- p ressureheatin gsurface , thewallthicknessisg enerall y3.0-4.0 mm , andtheouterdiameteris

                g enerall y 30-50mm , soitisver ydifficulttop re p aresam p leforfieldmetallo g ra p hicexamination.Ifthep i p eiscutfor

                sam p lin g , itisnotonl ydifficulttorecover , butalsoaffectsthep erformanceofthee q ui p ment.Therefore , basedonthe

                fieldmetallo g ra p hicexamination , a metallo g ra p hicexamination methodforhi g h-tem p eratureheatin gsurface ( p earlitic

                ferriteheatresistantsteelthin-walled ) p i p eofutilit yboilers wasstudied.Theresultsshowthatthe microstructure

                 mor p holo gy isclearandtheanal y sisresultisaccurateandreliableb yusin g the p ortablemetallo g ra p hicmicrosco p eandthe

                sam p le p re p arationmethod.Thismethodnotonl y o p timizedtheexaminationp rocess , butalsoshortenedtheexamination

                timeandim p rovedtheeconomicbenefitsoftheenter p rise.Atthesametime , itavoidedthedama g eofcuttin gp i p e , and

                solvedthe p roblemofdifficultweldin g recover y ofthin-walledp i p e.


                     Ke y words : utilit y boiler ; heatin gsurface ; thin-walled p i p e ; field metallo g ra p hicexamination ; p ortable

                 metallo g ra p hicmicrosco p e
               随着金相显微镜技术的不断发展及设备的不断                            金属材料的组织检测中发挥了重要的作用。尤其是
            完善, 如今的金相显微镜比早期的金相显微镜在成                            便携式金相显微镜的迅速发展, 极大地规避了以往
            像、 光源方面有了进一步的发展, 因此金相显微镜在                          现场取样的弊端, 而且随着图像捕捉及处理技术的
                                                               更新换代, 现在只需将显微镜与平板电脑连接就可

                                                               观察到清晰的显微组织形貌。
                收稿日期: 2020-06-04
                作者简介: 陈思思( 1987- ), 女, 工程师, 主要从事金属材料的显             电站锅炉管道的所有受热面, 长期处于高温、 高
            微组织研究工作, 1174012921@ qq .com
